CAT 315 Part Manual Page 647

Part Manual
HYDRAULIC SYSTEM
278-6438 LINES
GP-PUMP
–SYSTEM 20, WORK TOOL PRIORITY
S/N: CJN1 -UP
PART OF 259-755
7 CONTROL AR-AUXILIARY
AN ATTACHMENT
SMCS-5057 i02791350
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 1 193-9933 1HOSEAS
21 297-0647 1 VALVE GP-PRIORITY
31 278-6473 1 SUPPORT AS
I4 1 278-6476 1HOSEAS
I5 1 278-6480 1HOSEAS
I6 1 278-6484 1HOSEAS
I7 1 278-6488 1HOSEAS
81 278-6492 1 SUPPORT
91 278-6782 1 CONNECTOR AS
1 5K-9090 1 SEAL-O-RING
1 7M-8485 1 SEAL-O-RING
1 272-4264 1 CONNECTOR
10 1 087-3591 1 SPACER (15.5X30X12-MM THK)
11 1 148-8335 3 CONNECTOR AS
(EACH INCLUDES)
1 5K-9090 1 SEAL-O-RING
1 6V-8635 1 CONNECTOR
1 7M-8485 1 SEAL-O-RING
12 1 148-8336 1 CONNECTOR AS
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8636 1 CONNECTOR
13 1 148-8352 1 ELBOW AS
1 5K-9090 1 SEAL-O-RING
1 6V-9854 1 ELBOW
14 1 148-8355 1 ELBOW AS
1 5K-9090 1 SEAL-O-RING
1 6V-9005 1 ELBOW
1 7M-8485 1 SEAL-O-RING
15 1 148-8357 2 ELBOW AS
(EACH INCLUDES)
1 5K-9090 1 SEAL-O-RING
1 6V-9008 1 ELBOW
1 7M-8485 1 SEAL-O-RING
16 1 155-2027 3 CONNECTOR AS
(EACH INCLUDES)
1 5K-9090 1 SEAL-O-RING
1 7M-8485 1 SEAL-O-RING
1 8T-8898 1 CONNECTOR
17 1 177-1061 1 ELBOW AS
1 5K-9090 1 SEAL-O-RING
1 142-0038 1 ELBOW
18 1 5P-7468 1 CLIP (SLOT)
19 1 5P-7469 1 CLIP (TAB)
20 1 7G-5984 1 CLIP (TAB)
21 1 7G-5985 1 CLIP (SLOT)
22 1 8T-2525 1 GROMMET
23 1 278-6469 1 GROMMET
M24 1 8T-4139 4 BOLT (M12X1.75X30-MM)
M25 1 8T-4183 1 BOLT (M12X1.75X40-MM)
M26 1 8T-4192 3 BOLT (M12X1.75X25-MM)
27 1 8T-4223 12 WASHER-HARD (13.5X25.5X3-MM THK)
M28 1 8T-5001 4 BOLT (M12X1.75X130-MM)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
SEBP4861-02 1of2 HYDRAULIC SYSTEM 617
