CAT 315 Part Manual Page 850

Part Manual
WORK TOOLS
327-3623 BUCKET GP-GENERAL PURP OSE
S/N: CJN1 -UP
1074-MM (42-IN) WIDE X 0.7-C U M (1-CU YD) C APACITY. K-80 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6101 i03095205
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 327-3624 1 BUCKET AS-GENERAL PURPOSE 805
Y 2C-9589 1 PIN GP-BUCKET 823
Y 7Y-0729 1 SIDECUTTER GP 825
Y 229-6966 5 TIP GP-PENETRATION PLUS (K-80) 834
Y-SEPARATE ILLUST
RATION
<END>
327-3626 BUCKET GP-GENERAL PURP OSE
S/N: CJN1 -UP
1219-MM (48-IN) WIDE X 0.9-CU M (1.2-CU YD) CAPACITY. K-80 ADAPTERS, (6X)
AN ATTACHMENT
SMCS-6101 i03095214
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 327-3627 1 BUCKET AS-GENERAL PURPOSE 806
Y 2C-9589 1 PIN GP-BUCKET 823
Y 7Y-0729 1 SIDECUTTER GP 825
Y 229-6966 6 TIP GP-PENETRATION PLUS (K-80) 834
Y-SEPARATE ILLUSTRATION
<END>
327-3650 BUCKET G P-UT ILITY–DIT CH CLEANING
S/N: CJN1 -UP
1500-MM (59-IN) WIDE X 0.9-C U M (1.2-CU YD) CAPACITY
AN ATTACHMENT
SMCS-6101 i03095365
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 167-0278 1 BUCKET AS-UTILITY 818
Y 167-0316 1 EDGE GP-CUTTING 823
Y 2C-9589 1 PIN GP-BUCKET 823
Y-SEPARATE ILLUSTRATION
<END>
820 WORK TOOLS SEBP4861-02
