CAT 315 Part Manual Page 800

Part Manual
IMPLEMENTS
283-9006 STICK AR -HOE
S/N: CJN1 -UP
1.9-M (6.1-FT)
AN ATTACHMENT
SMCS-6502 i02761919
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 131-9964 1 LINES GP-STICK 624
Y 294-1360 1 STICK GP-HOE 779
Y-SEPARATE ILLUSTRATION
<END>
301-2461 STICK A R-HOE–REACH, ACCUGRADE READY
S/N: CJN1 -UP
3.1-M (10.2-FT)
AN ATTACHMENT
SMCS-6502 i02765898
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 131-9961 1 LINES GP-STICK 621
Y 303-8851 1 STICK GP-HOE (ACCUGRADE READY) 781
Y-SEPARATE ILLUSTRATION
<END>
301-2463 STICK A R-HOE–REACH, ACCUGRADE READY
S/N: CJN1 -UP
2.6-M (8.5-FT)
AN ATTACHMENT
SMCS-6502 i02761985
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 131-9962 1 LINES GP-STICK 622
Y 303-8848 1 STICK GP-HOE (ACCUGRADE READY) 780
Y-SEPARATE ILLUSTRATION
<END>
301-2576 STICK AR-HOE– HEAVY-DUTY
S/N: CJN1 -UP
2.6-M (8.5-FT)
AN ATTACHMENT
SMCS-6502 i03001027
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 131-9962 1 LINES GP-STICK 622
Y 315-0925 1 STICK GP-HOE 785
Y-SEPARATE ILLUSTRATION
<END>
770 IMPLEMENT S SEBP4861-02
