CAT 315 Part Manual Page 615

Part Manual
HYDRAULIC SYSTEM
289-5749 LINES
GP-PILOT
–ACCUGRADE, CAB
S/N: CJN1 -UP
PART OF 301-247
9, 301-2517, 330-8775 SPECIAL AR
AN ATTACHMENT
SMCS-5057, 5059 i02843759
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
I1 1 4I-0836 1HOSEAS
21 4I-9521 6 BAND-MARKER (RED, L1)
31 4I-9523 2 BAND-MARKER (B
LUE, L3)
41 6V-0852 3 CAP-DUST
51 7K-1181 2 STRAP-CABLE
Y6 1 123-2430 1 VALVE GP-SHUTTL
E
729
71 164-6874 1 FITTING AS-ELBOW
1 3J-1907 1 SEAL-O-RING
1 085-7356 1 FITTING
I8 1 207-6418 1HOSEAS
91 238-6189 2HOSEAS
I10 1 292-7198 1HOSEAS
Y11 1 297-0684 1 VALVE GP-SOLENOID & PRESS REDC 749
12 1 148-8336 2 CONNECTOR AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8636 1 CONNECTOR
13 1 148-8338 2 CONNECTOR AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 8T-0075 1 CONNECTOR
14 1 148-8378 3 ELBOW AS
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-8397 1 SEAL-O-RING
1 6V-8724 1 ELBOW
15 1 148-8407 1PLUGAS
1 3J-1907 1 SEAL-O-RING
1 9S-4191 1 PLUG-O-RING
16 1 150-4050 1 ELBOW AS
1 3J-1907 1 SEAL-O-RING
1 8T-0788 1 ELBOW
17 1 164-5567 3 COUPLER AS-QUICK DISCONNECT
(EACH INCLUDES)
1 3J-1907 1 SEAL-O-RING
1 6V-3965 1 FITTING (QUICK DISCONNECT)
18 1 6V-8397 2 SEAL-O-RING
M19 1 8T-6870 4 BOLT (M8X1.25X70-MM)
I-REFER TO HYDRAULIC INFORMATION SYSTEM
M-METRIC PART
Y-SEPARATE ILLUSTRATION
SEBP4861-02 1of2 HYDRAULIC SYSTEM 585
