CAT 315 Part Manual Page 395

Part Manual
UNDERCARRIAGE
194-1134 LINK A
S-TRACK
S/N: CJN1 -UP
PART OF 176-485
2, 179-3027, 179-3028 TRACK GP
AN ATTACHMENT
SMCS-4169, 4171 i01476355
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 9W-3138 43 LINK-TRACK-LH
21 095-0863 1 COTTER
31 8E-8586 1 LINK-MASTER-L
H
41 190-3523 43 BUSHING-TRACK
51 8E-8585 1 LINK-MASTER-RH
61 188-3064 1 PIN-TRACK MASTE
R
71 158-4381 2 SEAL-TRACK MASTER
81 9W-3137 43 LINK-TRACK-RH
91 6Y-8186 43 PIN-TRACK
10 1 158-4380 86 SEAL-TRACK
11 1 190-3524 1 BUSHING-MASTER
GRAPHIC #1 <END> g00770657
SEBP4861-02
1of1 UNDERCARRIAGE 365
