HYDRAULIC SYSTEM

275-1699 LINES GP-FRONT (contd. ) i03001033

NOTE

REF

GRAPHIC

REF PART NUM BER QTY

PART NAM E

123456(PRODUCT LEVEL)

SEE

PAGE

27 1,2 8T-4121 6 WASHER-HARD (11

X21X2.5-MM THK)

M28 2 8T-4136 4 BOLT (M10X1.5X25-MM)

M29 1 8T-4139 2 BOLT (M12X1.75X30-MM)

M30 2 8T-4183 4 BOLT (M12X1.75X4

0-MM)

M31 1 8T-4195 2 BOLT (M10X1.5X30-MM)

32 1,2 8T-4223 12 WASHER-HARD (13.5X25.5X3-MM THK)

M331,2 8T-4956 6 BOLT (M12X1.75X3

5-MM)

34 1 8T-7087 1 GROMMET

35 1 7K-1181 2 STRAP-CABLE

36 1 282-7106 1 GROMMET

C-CHANGE FROM PREVIOUS TYPE

I-REFER TO HYDRAULIC INFORMATION SYSTEM

M-METRIC PART

Y-SEPARATE ILLUSTRATION
