CAT 315 Part Manual Page 343

Part Manual
FRAME AND BODY
297-7558 FRAME
GP-UPPER
–ACCUGRADE
S/N: CJN1 -UP
PART OF 301-247
9, 301-2517, 330-8775 SPECIAL AR
AN ATTACHMENT
SMCS-7051 i02840342
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
B1 1 093-0086 4 SHIM (1-MM THK)
B2 1 093-0118 2 SHIM (2-MM THK)
31 093-0349 3 WASHER (22X60X
6-MM THK)
41 107-9739 2PINAS
51 118-5982 2 SPACER (73X105X14-MM THK)
B6 1 133-2424 2 SHIM (0.5-MM THK
)
71 212-2838 2 SHIM (2-MM THK)
J8 1 245-7900 1CAP
J9 1 245-7901 1CAP
10 1 260-2459 1 FRAME AS-UPPER
11 1 303-8860 1PINAS
B12 1 308-8775 1 SHIM (0.5-MM THK)
B13 1 308-8776 2 SHIM (1-MM THK)
B14 1 308-8777 1 SHIM (2-MM THK)
15 1 308-8914 1 PLATE
M16 1 096-4883 2 LOCKNUT (M10X1.15-THD)
M17 1 7X-2561 1 BOLT (M20X2.5X35-MM)
18 1 8T-4121 2 WASHER-HARD (11X2
1X2.5-MM THK)
M19 1 8T-4186 2 BOLT (M10X1.5X40-MM)
M20 1 8T-4780 2 BOLT (M20X2.5X30-MM)
B-USE AS REQUIRED
J-USED ONLY ON MACHIN
ES WITHOUT LOWER WIPER
M-METRIC PART
SEBP4861-02 1of2 FRAME AND BODY 313
