CAT 315 Part Manual Page 823

Part Manual
WORK TOOLS
239-2517 BUCKET & A DJUSTER GP–HEAVY-DUTY ROCK
S/N: CJN1 -UP
1076-MM (42-IN) WIDE X 0.7-C U M (1-CU YD) C APACITY. K-90 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6503, 6513 i02895089
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 239-2527 1 BUCKET AS-HEAV
Y DUTY ROCK
809
–OR–
Y 305-1697 1 BUCKET AS-HEAVY DUTY ROCK 816
Y-SEPARATE ILLUST
RATION
<END>
239-2518 BUCKET & A DJUSTER GP–HEAVY-DUTY ROCK
S/N: CJN1 -UP
1228-MM (48-IN) WIDE X 0.9-CU M (1.2-CU YD) CAPACITY. K-90 ADAPTERS, (6X)
AN ATTACHMENT
SMCS-6503, 6513 i03034901
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 239-2528 1 BUCKET AS-HEAVY DUTY ROCK 810
–OR–
Y 305-1698 1 BUCKET AS-HEAVY DUTY ROCK 817
Y-SEPARATE ILLUSTRATION
<END>
305-1667 BUCKET & A DJUSTER GP–HEAVY-DUTY ROCK
S/N: CJN1 -UP
927-MM (36-IN) WIDE X 0 .6-CU M (0.8-CU YD) CAPACITY. J-350 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6503, 6513 i02788578
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 305-1668 1 BUCKET AS-HEAVY DUTY ROCK 811
Y-SEPARATE ILLUSTRATION
<END>
305-1671 BUCKET & A DJUSTER GP–HEAVY-DUTY ROCK
S/N: CJN1 -UP
1079-MM (42-IN) WIDE X 0.7-CU M (0.9-CU YD) CAPASITY. J-350 ADAPTERS, (5X)
AN ATTACHMENT
SMCS-6503, 6513 i03153788
NOTE PART NUMBER QTY
PART NAM E
123456(PRODUCT LEVEL)
SEE
PAGE
Y 106-6757 1 ADJUSTER GP-BUCKET 786
Y 305-1672 1 BUCKET AS-HEAVY DUTY ROCK 812
Y-SEPARATE ILLUSTRATION
<END>
SEBP4861-02 WORK TOOLS 793
