CAT 315 Part Manual Page 203

Part Manual
ELECTRICAL AND STARTING SYSTEM
238-1628 LIGHT
ING G P-FL OOD
–CAB GUARD
S/N: CJN1 -UP
AN ATTACHMENT
SMCS-1434 i03130082
NOTE
REF
NO
GRAPHIC
REF PART NUM BER QTY
PART NAM E
123456(PRODUCT LEVEL
)
SEE
PAGE
11 3S-2093 1 STRAP-CABLE
21 163-6704 1 TIMER AS (TIME DELAY LIGHTING)
1 186-3735 5 PIN-CONNECTOR
(16-GA TO 18-GA)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
1 102-8803 1 KIT-RECEPTACLE (3-PIN)
(EACH RECEPTACL
E KIT INCLUDES RECEPTACLE AS &
WEDGE)
31 163-6795 2 STRAP-CABLE
41 170-9295 2 HARNESS AS-LIGHTING (CAB FLOODLIGHTS, FRONT)
(EACH INCLUDES)
1 7Y-3962 1 TERMINAL (CONNECTOR)
1 7Y-3964 1 TUBE (CONNECTOR TERMINAL)
1 7Y-3963 1 TERMINAL (RECEPTA
CLE)
1 7Y-3965 1 TUBE (RECEPTACLE TERMINAL)
51 183-1035 2 LAMP GP-FLOOD (CANOPY)
1 9X-3463 1 LAMP-HALOGEN (24-
VOLT, 65-WATT) (CANOPY)
61 238-2326 1 PLATE AS
71 8T-4121 4 WASHER-HARD (11X21X2.5-MM THK)
M8 1 8T-4133 2 NUT (M10X1.5-THD)
M9 1 8T-4137 2 BOLT (M10X1.5X20-MM)
M10 1 9X-2042 2 SCREW-TRUSS HEAD (M6X1X12-MM)
M11 1 9X-2043 2 SCREW-TRUSS HEAD (M
6X1X14-MM)
M-METRIC PART
SEBP4861-02 1of2 ELECTRICAL AND STARTING SYSTEM 173
